DR 22-Ton User Manual

8 DR
®
HORIZONTAL/VERTICAL LOG SPLITTER
Specifications
Model
22 Ton 28 Ton 34 Ton
Engine
See engine manual See engine manual See engine manual
Pump
Two-Stage, 10 gpm Two-Stage, 10 gpm Two-Stage, 15 gpm
Cylinder (Bore x Stroke)
4 in. x 24 in. 4.5 in. x 24 in. 5 in. x 24 in.
Maximum Splitting Force
22 Tons* 28 Tons*
34 Tons*
Hydraulic Pressure
3400 psi* 3450 psi*
3500 psi*
Maximum Log Length
25 in. 25 in.
25 in.
Wedge Height
8 in. 8 in. 8 in.
Cycle Time
Forward
8 Seconds* 8 Seconds* 7 Seconds*
Reverse
5 Seconds* 5 Seconds* 4 Seconds*
Wheels
16 x 4.8 x 8 in. 16 x 4.8 x 8 in. 16 x 4.8 x 8 in.
Hydraulic Capacity
Approx. 4 Gallons Approx. 4 Gallons Approx. 5
Gallons
Height (Horizontal / Vertical Position)
41.5 / 71 in. 41.5 / 71 in. 41.5 / 71 in.
Length (Horizontal / Vertical Position)
87 / 84 in. 87 / 84 in. 87 / 84 in.
Width
41 in. 41 in.
41 in.
Net Weight
474 lbs 512 lbs
549 lbs
*Tonnage and cycle times may vary dependent upon mechanical and environmental conditions.

DR 22-Ton Specifications

General

Brand	DR
Model	22-Ton
Category	Log Splitter
Language	English
