DR PILOT 5TE - Chapter 6: Parts Lists, Schematic Diagrams and Warranty

16 DR
®
5-TON ELECTRIC LOG SPLITTER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List - DR 5-TON ELECTRIC LOG SPLITTER
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0000937966 Motor-1500w Ip54
2 A0000937990 Cylindrical Pin-2.5od X 4
3 A0000944997 O-Ring-46.2 X 1.8g
4 A0000937986 Sleeve-Rolled Shaft
5 A0000937995 Cap-Motor Cover
6 A0000937996 Wire Retaining Ring-10
7 A0000937999 Gear Shaft
8 A0000937998 Steel Ball-2.5od
9 A0000937990 Cylindrical Pin-2.5od X 4
10 A0000937997 Gear-Pump
11 A0000938001 End Cover-Gear Pump
12 A0000938005 Bolt-M8 X 30
13 A0000940903 Washer-M8 Split Lock
14 302471 Washer-M8
15 A0000938004 Bolt-M8 X 55
16 A0000938015 O-Ring-11.8 X 1.8g
17 A0001077360 Frame
18 A0000938043 Sliding Frame
19 A0000938040 Bolt-M12 X 30
20 A0000938044 Washer-M12 Flat
21 A0000938041 Splitting Head
22 A0000938046 Nut-M12
23 A0000938042 Backing Plate-Top
24 A0000938047 Backing Plate-Bottom
25 A0000938038 O-Ring-48.7 X 3.55g
26 A0000938039 Washer-Front Cover
27 A0000938027 Locating Bolt
28 A0000938028 Washer-Copper M14
29 A0000938029 O-Ring-14 X 1.8g
30 A0000938037 Cover-Front
31 A0000938030 Spring- Ii
32 A0000944998 Activity Kit
33 A0000938032 O-Ring-11.2 X 1.8g
34 A0000938031 Control Valve
35 A0000938033 Stroke Valve
36 A0000938034 O-Ring-5.6 X 1.8g
37 A0000938035 Spring-I
38 A0000938036 Split Ring
39 A0000938026 Plastic Sleeve
40 A0000938024 Nut-M6
41 A0000944999 Set Screw-Internal Hex Head M6 X 20
42 A0000938023 Hex Nut
43 A0000938022 Bushing-Short Shaft
44 A0000937683 Washer-Lock 10
Ref# Part# Description
45 A0000938007 Cap Nut-M10
46 A0000938011 Washer-Flat 10
47 A0000938000 O-Ring-9.5 X 2.65g
48 A0000938013 Nut-M10
49 A0000938021 O-Ring-4.87 X 1.8g
50 A0000938020 Short Axle
51 A0000938019 Adjustment Spring
52 A0000938018 Cone Valve
53 A0000938017 Oil Valve
54 A0000938025 Set Screw-Internal Hex Head M14 X 14
55 A0000943166 O-Ring-11.8 X 2.2g
56 A0000938014 Hex Bolt
57 A0000938012 Guard Plate
58 A0000938009 Knob-Handle
59 A0000938008 Actuation Handle
60 A0000943790 Pin-Actuation Handle
61 A0000943791 Housing-Actuation Handle
62 A0000943792 Cap Screw-M5 X 16
63 A0000937988 Washer-M5 Split Lock
64 A0000937980 Washer-M5 Flat
65 A0000938072 Nut-Nylon Lock M14 X 2
66 A0000938052 Nut-M14
67 A0000938070 Rod-Piston
68 A0000938069 Bolt-Dipstick
69 A0000938068 O-Ring-11.8 X 2.65g
70 A0000938067 Dipstick-Oil Level
71 A0000938066 Dust Ring-Fc30 X 38 X 5
72 A0000938065 Screw-Butterfly
73 A0000938064 O-Ring-3.6 X 1.8g
74 A0000938063 Cover-Back
75 A0000938062 Washer-Rear End Cover
76 A0000938061 Compression Spring
77 A0000938056 Stud-Ram
78 A0000938059 O-Ring-43.7 X 3.55g
79 A0000938060 Slip Ring
80 A0000938058 Piston-Oil
81 A0000938057 Oil Cylinder
82 A0000938051 Tube Leg-Right
83 A0000938054 Tube Leg-Left
84 A0000938050 Wheel
85 A0000938044 Washer-M12 Flat
86 A0000938049 Cotter Pin
87 A0000938048 Roller Shaft
88 A0000938055 Sleeve-Round Handle
