22 DR
®
POWER GRADER
Chapter 6: Parts Lists, Schematic Diagrams and Warranty
When your machine was assembled at the factory, we used Bolts, Flat Washers and Nuts in many areas. When you order
replacement Hardware, we will send Flanged Bolts and Locknuts (Flat Washers not required) as shown in the following
illustrations.
Parts List – GRADER BOX ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 37574 Crossmember, Frame, 48" W/ Weight
Limit Label
2 37573 Crossmember, Frame, 48" W/ Speed
Limit Label
3 37572 Rail, Frame, Right, W/ Label
4 37571 Rail, Frame, Left, W/ Label
5 36713 Tooth Bar, 48"
6 36711 Board, Mold, 48"
7 36683 Bracket, Axle
8 36710 Strap, Weight Box, 48"
9 36706 Spacer, Tooth Bar
10 36677 Assembly, Axle,48"
11 36689 Bracket, Spring, Cable
12 19147 Wheel, 8", Semi Pneumatic
13 33333 Nut, Nylon Lock, Flanged, 3/8-16
14 37184 Bolt,HHCS,Flanged, 3/8-16 x 2-1/2", Gr8
Ref# Part# Description
15 18064 Washer, .8" ID, 1.5" OD X .11"
16 36737 Bolt, Shoulder, 1/2 X 3/8l, 3/8-16
17 36739 Bolt, HHCS, Flanged, 3/8-16 x 3/4", Gr5,
ZP
18 36702 Spacer, Rail
19 37185 Bolt, HHCS, Flanged, 1/2-13 x 6", Gr8
20 37187 Bolt, HHCS, Flanged, 1/2-13 x 3-3/4",
Gr8
21 33335 Nut, Nylon Lock, Flanged, 1/2-13
22 37190 Pin, Cotter, 3/32" X 1", ZP
23 37186 Spacer, Rail, Center
24 37191 Pin, Snap Safety, 5/16" X 3"
25 33350 Bolt, Hex, Flange, 3/8-16 X 2"
26 37284 Label, Limit, Weight
27 37281 Label, Limit, Speed
28 34139 Label, DR Logo, 4" Black
To Next Page
