Page #24 background image
24 DR
®
POWER GRADER
Parts List – TOW BAR ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 37235 Bracket, Hitch Adjustment
2 36676 Assembly, Hitch, Pin
3 33333 Nut, Nylon Lock, Flanged, 3/8-16
4 36680 U-bolt, Post
5 37184 Bolt, HHCS, Flanged, 3/8-16 x 2-1/2",
Gr8
6 36704 Cable, Adjust, Height, Manual
7 36685 Post, Crank
8 12170 Washer, Flat 3/8, ZP, ANSI Narrow
9 36715 Ring, Retaining, External, 3/8"
10 36678 Bushing, Cable
11 36703 Hitch, Tow Hook
12 37234 Bracket, Anti-Rotation, Hook, Tow
Ref# Part# Description
13 37236 Lanyard, Hair Pin
14 37237 Pin, Shear, 1/2"
15 37283 Label, Adjust, Hitch
16 11985 Bolt, HCS, 3/8-16 X 1-1/2", Gr5, ZP
17 18081 Washer, Medium Split Lock, 3/8"
18 18759 Plug, Square, 1.5" x 1.5"
19 37505 Plug, Rectangular, 1.5" X 1"
20 37570 Bar, Tow, PGR W/Label
21 37567 Bracket, Hitch Adjustment, W/Labels
22 37569 Plate, Backing, U-bolt, Sliding W/Label
23 37280 Label, Pin, Shear
