26 DR

POWER GRADER

Parts List – CONTROL BOX ASSEMBLY

Note: Part numbers listed are available through DR Power Equipment.

Ref# Part# Description

1 366561 10-24 X 1/4" Slotted Head, Steel

2 366931 Clamp, Collar, Shaft, 1/2"

3 366981 Handle, Crank, Slip Through

4 366871 Bushing, Adjust, Height

5 375681 Box, Control, Adjust, Height W/Labels

6 366941 Slider, Adjust, Height

7 366901 Rod, Acme, Adjust, Height

8 366951 1/2-8, Nut, Acme

Ref# Part# Description

9 366961 1/2-8, Nut, Coupling, Acme

10 366911 Cover, Box, Control, Adjust, Height

11 121701 Washer, Flat 3/8", ZP, Ansi Narrow

12 126831 Nut, 3/8-16, Gr5,ZP

13 367051 Knob, Crank

14 372401 Ring, Snap, Retaining, External, 3/8"

15 372411 Washer, Flat, .375" ID, .5" OD

16 37282 Label, EZ Dial
