DR PREMIER 320 - Chapter 6: Parts Lists and Schematic Diagrams

24 DR
®
PRO CHIPPER SHREDDER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Hopper, Chute and Discharge
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0001994505 Deflector, Discharge (PRO 420)
A0001364158 Deflector, Discharge (PREMIER
320)
2 A0002277800 Hopper w/Labels, 4in (PRO 420)
A0002277796 Hopper w/Labels, 3in (PREMIER
320)
3 A0002277801 Chute w/Labels, 4in (PRO 420)
A0002277797 Chute w/Labels, 3in (PREMIER
320)
4 A0001363954 Guard, Chipper Chute, (PRO 420)
365141 Guard, Chipper Chute (PREMIER
320)
5 A0001294572 Bracket, Chute Guard (PRO 420)
365151 Plate, Guard (PREMIER 320)
6 365151 Plate, Guard
7 365251 Guard, Shredder Hopper
8 365261 Support, Hopper Guard
9 A0001244988 Handle
Ref# Part# Description
10 333311 Nut, Nylon Lock, Flanged, 1/4-20
11 386401 Bolt, HCS, 5/16-18 X 6″, GR5, ZP
(PRO 420)
385971 Bolt, Housing, 5/16-18 X 5.5"
(PREMIER 320)
12 333321 Nut, Nylon Lock, Flanged, 5/16-18
13 365211 Bolt, Hex, Flange, 1/4-20 X 5/8″, ZP
14 10000043872 Screw, Button Hex Hd, 5/16-18 X
5/8", GR5, ZP
15 392831 Label, Danger, Discharge
16 392821 Label, Danger, Safety
17 A0000181455 Label, DR Logo, 5.5″ Die Cut
18 10000026298 Label, Operating (PRO 420)
A0004444433 Label, Operating (PREMIER 320)
19 A0002192920 Label, CS4 PRO 420
A0002192919 Label, CS4 PREMIER 320
20 365441 SUPPORT, GUARD HOPPER
