Chapter 6: Parts Lists, Schematic Diagrams and Warranty
Parts List – PRO-62V CHAINSAW
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 41815 Auxiliary Handle
2 41816 Left Shell
3 41817 Rear Cover
4 41818 Hexalobular Socket Pan Head Screws
5 41819 Flat Washer
6 41820 Left Shaft Sleeve
7 41821 Torsional Spring
8 41822 Front Damper
9 41823 Right Shaft Sleeve
10 41824 Cross Recessed Pan Head Tapping
Screws
11 41825 Switch Pressing Plate
12 41826 Micro switch
13 42101 Hexalobular Socket Pan Head Tapping
Screws
14 41828 Flat Washer
15 41829 Switch Connecting Rod
16 41830 Controller
17 41831 Pressing Plate
18 41832 Brake Elastic Piece
19 41833 Transmission Block
20 41834 Brake Set
21 41835 Hexalobular Socket Pan Head Tapping
Screws
22 41836 Pressing Plate Cover
23 41837 Adjusting Screw Stem
24 41838 Pressing Plate of Adjusting Screw Stem
25 41839 Adjusting Gear
26 41840 Clamp
27 41841 Oil Tube
28 41842 Oil Tube Spring
29 41800 Hexalobular Socket Pan Head Tapping
Screws
30 41844 Oil Tube Connector
31 41845 Seal Ring for Oil Tube Connector
32 41846 Hexalobular Socket Pan Head Tapping
Screws
33 41847 Front Handle Supporting Base
34 41848 Seal Ring
35 41849 Cross Recessed Countersunk Head
Tapping Screws
Ref# Part# Description
36 41850 Sprocket
37 41851 Tensioning Knob
38 41852 Shell Cover Plate
39 41853 Fan Shroud
40 41854 Brushless Motor
41 41855 Oil Pump Set
42 41856 Flat Key
43 41857 Flat Washer
44 41858 Oil Pump Worm
45 41859 Oil Pump Top Cover
46 41860 Spring Washer
47 41861 Cross Recessed Pan Head Screws
48 41862 Brake Disc
49 41863 Circlip for Shaft
50 41864 Brake Compressed Spring
51 41865 Brake Disc Top Cover
52 41866 Brake Connecting Rod Cover
53 41867 609 Bearing Pressing Plate
54 41868 Deep Groove Ball Bearing
55 41869 Motor Shaft Sleeve
56 41870 Six-foot Sprocket
57 41871 Sprocket Pressing Plate
58 41872 E-Shaped Ring-Shield
59 41873 Right Shell
60 41874 Hexalobular Socket Pan Head Tapping
Screws
61 41875 Circlip for Shaft
62 41876 Non-Slip Mat
63 41877 Sealing Gasket
64 41878 Side Cover
65 41879 Gear-Locking Elastic Piece
66 41880 Lock Knob
67 41881 Shaft
68 41882 Lock Knob Wrench
69 41883 Tensioning Bolt
70 41884 Tensioning Nut
71 41885 Adjustable Pressing Plate
72 41886 Breather Valve
73 41887 Oiler
