Small Box Parts (Figure 5):
Item # Part # Description Qty
1 ............. A0001844373 ..... Bracket, Stop ............................................... 2
2 ............. 354421 ............... Strap and Hook Set .................................... 1
3 ............. 338021 ............... Bracket, Axle ................................................ 2
4 ............. 350211 ............... Hardware Set, Wheels ................................ 1
5 ............. A0002281395 ..... Hardware Set, Enclosure ............................ 1
6 ............. 388671 ............... Hardware Set, Power Unit .......................... 1
7 ............. 337911 ............... Retainer, Enclosure, Front .......................... 2
Master Tool List:
Item # Description Qty
1 ............. Ratchet ............... ..................................................................... 1
2 ............. 5/16" Wrench .... ..................................................................... 1
3 ............. 7/16" Wrench .... ..................................................................... 1
4 ............. 7/16" Socket ...... ..................................................................... 1
5 ............. 1/2" Wrench ...... ..................................................................... 1
6 ............. 1/2" Deep Socket .................................................................... 1
7 ............. 9/16" Wrench .... ..................................................................... 1
8 ............. 9/16" Deep Socket .................................................................. 1
9 ............. 3/4" Wrench ...... ..................................................................... 1
10 ........... 3/4" Socket ........ ..................................................................... 1
11 ........... 13mm Wrench or Adjustable Wrench .................................... 1
12 ........... Scissors or diagonal cutters .................................................... 1
13 ........... Pliers .................. ..................................................................... 1
14 ........... Wire Cutters ....... ..................................................................... 1
15 ........... Hammer ............ ..................................................................... 1
16 ........... Utility Knife ........ ..................................................................... 1
17 ........... Flat head Screwdriver or 7mm Wrench .................................. 1
18 ........... Tire Pressure Gauge ................................................................ 1
19 ........... Air pump or compressor ......................................................... 1
20 ........... Safety Glasses…....................................................................... 1
21 ........... Floor Jack……..….. .................................................................... 1
Figure 5
1
3
4
2
5
7
6
