DR PRO-XL User Manual

CONTACT US AT www.DRpower.com 25
9. Loosen the Hose Bridge Clamp at the end of the short Hose using a Flat Head Screwdrive or 7mm Wrench and slide the
Hose onto the Impeller Housing flange until the Bridge Clamp is just past the retaining tab (Figure 62).
10. Tighten the Hose Bridge Clamp tightly to secure the Hose to the Impeller Housing.
11. Support the Hose with the Rubber Strap by hooking one end into the Support Loop, going under the Coupling and securing
the other end onto the Support Loop (Figure 63).
Coupling
Figure 63
Hose Support
Rubber Strap
Figure 62
Hose
Clamp
Retaining
Tab
Clamp
Area
Impeller
Housing
