24 DR
®
R225, R300 and R390 Engines
2. Manual Start Engine with Oil Protection System
Bl
BLACK
Y
YELLOW
G
GREEN
Ignition Coil
Spark Plug
Engine Switch
Y
Bl
Y
Y
Bl
Oil Sensor
Oil Protector
