36 DR
®
FIELD and BRUSH MOWER
Parts List – Drive Assembly (Kawasaki)
Note: Part numbers listed are available through DR Power Equipment.
Note: Items 1 and 4 thru 10 are on all models.
Ref# Part# Description
1 A0000646671 Belt, A38, 1/2″ X 40″
2 333321 Nut, Nylon Lock, Flanged, 5/16-18
3 393541 Bolt, Hex, Flange, 5/16-18 X 1.00″,
GR5, ZP
4 A0000560848 Clutch, Mechanical
5 111731 Screw, 5/16-18 X 1/2″, TRI
6 223241 Bolt, HCS, 7/16-20 x 2.75″, GR8, ZP
7 A0000367010 Washer, Split, 7/16″ GR8
8 A0000646517 Frame
9 A0000646621 Cover Plate, Rear
10 A0000646670 Belt, Bk78, 5/8″ X 80″
11 A0000974583 Engine, Kawasaki, FS600V, 18.5hp, ES
Ref# Part# Description
12 A0000702439 Muffler Support, Right
13 A0000702440 Muffler Support, Left
14 A0001903710 Guard, Muffler, Outer
15 A0001104312 Exhaust, Muffler
16 220981 Bolt, Hex Head, M8 X 16
17 289901 Screw, Unsltd Trilobe, 3/8-16 X 1″
18 333421 Nut, Nylon Lock, Flanged, M8-1.25,
CL8, ZP
19 A0000930250 Conduit, Hose and Cable
20 A0001903708 Guard, Muffler
21 365211 Bolt, Hex, Flange, 1/4-20 X 5/8″, ZP
