38 DR
®
FIELD and BRUSH MOWER
Parts List – Drive Assembly (Honda)
Note: Part numbers listed are available through DR Power Equipment.
Note: Items 9 thru 16 are on all models.
Ref# Part# Description
1 333321 Nut, Nylon Lock, Flanged, 5/16-18
2 A0000655096 Recoil Holder, Wire Form
3 A0000560846 Engine, Honda GXV390, 10.2HP, MS
4 112431 Washer, Lock, 5/16
5 A0001346725 Bolt, HCS, 5/16-24 X 1″, GR5 ZP
6 150451 Bolt, HCS, 5/16-18 X 1-3/4″, GR5 ZP
7 A0000952591 Barb Fitting, 3/8″ Hose ID, M20
Thread
8 350381 Nut, Nylon lock, Flange, 10-24, ZP
Ref# Part# Description
9 A0000560848 Clutch, Mechanical
10 111731 Screw, 5/16-18 X 1/2″, TRI
11 223241 Bolt, HCS, 7/16-20 x 2.75″, GR8, ZP
12 A0000367010 Washer, Split, 7/16″ GR8
13 A0000646517 Frame
14 A0000646621 Cover Plate, Rea
15 A0000646670 Belt, Bk78, 5/8″ X 80″
16 A0000646671 Belt, A38, 1/2″ X 40″
Not Shown
A0001645291 Label, Choke Symbol
