Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 55
Operating concept
the user docks an M540 and it is unable to
communicate with the Cockpit?
– An alarm of medium priority sounds at the Cockpit,
at the M540, and at the ICS (provided the patient is
admitted there).
– The message M540 communication failure
appears at the Cockpit.
– The M540 continues to monitor the patient and
provides acoustic and optical alarm signals.
Alarm behavior
an M540 whose acoustic alarm signals have
been paused docks to a Cockpit?
All acoustic alarm signals are paused for two minutes
on both devices.
the user docks an M540 with a different
alarm pause state than that of the Cockpit?
Both devices observe the remaining alarm pause
interval.
Connection/power problems
there is a power supply failure? – The LEDs on the front indicate that the Cockpit and
the M540 are on battery charge.
– The Cockpit sounds an alarm of medium priority
and switches to battery charge for up to five
minutes before performing a safe shutdown.
– The M540 switches to battery charge for up to three
hours before shutting down.
the system cable is disconnected from the
power supply or the M500?
– The Cockpit sounds an alarm tone of low priority.
– The Cockpit displays the message Please plug in
system cable in the header bar and the message
Disconnected from M540 appears in the
monitoring area.
– The Cockpit no longer displays any parameters
and waveforms.
What happens if... Behavior
