13 | Dräger RVP - Communication | Middelborg/Olsson | November 2011
Dräger Regard 3900
display board
Connection Regard 3900 Modbus
Gateway cable to Regard 3900 display
board (Connector for Regard 3900
Configuration Cable)
Regard 3900 Modbus
Gateway cable
(SC00084)
Connector for
Regard 3900
configuration cable
(4208785)
Connection:
Cable Gateway
PIN 2 High
PIN 4 Low
Regard 3900
Modbus Gateway
(SC00083)
Communication Regard 3900
Regard 3900 Modbus Gateway
Dräger RVP - Communication
RVP 3900
