GB
If you stop the winch under load, put the stop blocks under
the wheels of the vehicle or under the load. Do not stand
behind the vehicle/load while putting the stop blocks.
CONNECTION OF THE HYDRAULIC
WINCH
DWHI 200 HD
DWHI 10000 HD
DWHI 12000 HD
DWHI 15000 HD
DWHI 18000 HD
DWHI 20000 HD WINCHES
Connection diagram - see section A at the end of the man-
ual.
Open system
12 or 24 volt battery, depending on the type of
solenoid valves; the vehicle battery can be used
The solenoid
valves are controlled using a wired or wireless remote con-
troller. Ports A and B should be connected to the ports sup-
plying the hydraulic motor. Port P is used to supply hydrau-
lic oil from the pump. Port T (overow) is used to drain
excess oil from the hydraulic block.
Maximum oil ow 60 l/min. The pump should pro-
vide a maximum pressure of 140 bar.
!
ATTENTION
1.Helping the winch by using the car engine may
cause sudden jerks of the cable resulting in perma-
nent damage to the winch.
2.The pulled vehicle may not be in any gear and the
automatic transmission may not be in “park” posi-
tion. Otherwise serious damage may occur.
3.Do not wrap the hooks with the cable. This may
lead to damage of these elements and the cable.
Use the original thimble (eye) on the cable, shack-
les or snatch block.
4.Keep at a distance from the winch and cable in
operation.
5.Do not allow third parties to come near the winch
or cable in operation. Any cracked or sliding cable
is a serious threat to life and health.
6. Having nished work, disconnect the winch from
the power supply so that it can not be accidentally
switched on.
