Dramm HYDRA - Pressure Regulator Valve Parts List

Pressure Regulator Valve Parts List
Hydra Sprayer Manual 17
2-1 546849 Pressure Regulator Valve 1
2-2 540936 Grip 1
2-3 088913 Cap Screw 1
2-4 081039 Nut 1
2-5 087483 Screw 2
2-6 088912 Cap Screw 1
2-7 106495 Guide 1
2-8 106499 Washer 1
2-9 541769 Retainer 1
2-10 109298 Spring 1
2-11 546500 Body 1
2-12 107221 Spring 1
2-13 106498 Ball 1
2-14 543591 Piston Assembly 1
2-15 103306 Sleeve 1
2-16 019261 O-Ring 1
2-17 543507 Valve Seat 1
2-18 019261 O-Ring 1
2-19 542258 Tee 1
2-20 541796 Cock Assembly 1
I
TEM
# P
ART
# D
ESCRIPTION
Q
UANTITY
