SPRAY OPERATION
1. After following the start up, to increase the spray
pressure, turn the pressure control knob to the desired
setting. (B) You may use any of these settings for
spraying, as the unit will operate properly at all
settings.
2. To begin spraying, pull the lever to the gun. A latch is
provided to hold the level open to reduce operator
fatigue. (C)
C A U T I O N: Do not direct the spray at yourself or
others, as injury may occur. On higher pressure
settings, the spray stream may cut or inject spray
under your skin. Always wear proper personal
protective gear when spraying.
3. Spray Pattern: Adjustment of the spray pattern is
made using the lever on the side of the gun. The
pattern will adjust from a straight stream to a fine
cone mist. (D)
4. Hose Reel: The Hydra MultiSpray comes standard
with a variable drag lockable hose reel. The reel may
be locked in position to prevent the hose from
unwinding further than wanted. (E) The variable
drag on the reel places variable tension on the reel to
prevent freewheeling of the reel during unwinding.
The drag has a lever to activate it. A nut allows for
tension adjustment. (F)
B.
Hydra Sprayer 7
Operation
SHUT-DOWN
1. After spraying until the tank is empty, turn the unit
off.
2. Add clear water to the tank. Start the machine and
spray until empty flushing out the pump hose and
gun.
3. Clean any residue from the unit.
4. Return the regulator to the START position.
5. Store the unit in a clean dry place.
6. Do Not allow the unit to freeze as any water left in
the unit will expand and damage the machine.
C.
E.
F.
D.
