Draper 20514 - Refit of Motor Housing; Connecting the Flexible Hose; Use of Attachments

9. SETTING THE VACUUM CLEANER
FIG. 5
9.4 REFIT OF MOTOR HOUSING - FIG. 5
The motor housing is secured using the two retaining
clips .
FIG. 6
9.5 CONNECT THE FLEXIBLE HOSE - FIG. 6
Push the flexible hose  into the connector, turn
anti-clockwise to lock. To remove the flexible hose, twist
hose clockwise and pull.


FIG.7
9.6 USE OF ATTACHMENTS - FIG. 7
The combination attachment  to be used on hard
floors, parquet, cork, vinyl, ceramic, etc.
Any of the other attachments may be used depending
upon the specific application. They are attached in the
same way as explained previously.

12
