Draper 26920 - PREPARING & FUNCTION; Preparation and Component Overview

- 3 -
STUD DETECTION
FACE
VOLTAGE/
METAL
DETECTION
FACE
BATTERY
COMPARTMENT
COVER
TRIMMER
FOR STUD
DETECTION
TRIMMER FOR
VOLTAGE/
METAL
DETECTOR
BUZZER
RED LED
INDICATOR
GREEN LED
INDICATOR
SENSITIVITY ADJUSTING
DIAL (STUD DETECTOR)
SELECTION SWITCH
SENSITIVITY ADJUSTING DIAL
(VOLTAGE/METAL DETECTOR)
GREEN ‘ON’ LED
RED LED INDICATOR
Fig.2.
PREPARING & FUNCTION
PREPARATION:
●
Slide out the battery compartment cover on the back of the
unit and connect a new 9V PP3 battery.
●
Securely snap cover back in place and the unit is ready for
use.
●
The blue square selector switch should be carefully located.
Fig.1.
