Section 4.2 -Operator Code
Touch any key to start. At “Enter Password”, enter User Password Code.
Select Mode will be displayed with the options:
1 Device OP Mode.
2 Group Op Mode.
1 Device Op Mode – Enter Device Number To Operate and press Enter
(Example: Press 01, Enter to raise or lower device 01).
2 Group Op Mode – Enter Group Number To Operate and press Enter
(Example: Press 01, Enter to raise or lower Group 01).
Section 5 - Define Relay Box Addresses for EZ Pad Plus Touch Pad
Touch Pads are shipped without any advance programming, so it is necessary to tell each EZ-Pad Plus touch pad what relay box addresses are for your specific network.
Relay box definitions are stored in each touch panel, so it will be necessary to define relay box addresses in every Touch Pad.
1 Touch any key to start. At “Enter Password”, enter the Supervisor Password Code.
2 Press the Set Up key. This will show the options of: 1) Config System; 2) Config Group; 3) Config Device Box.
3
Select - 3) Config Device Box.
This will show the options of:
1 Display Device Box – Shows already defined relay boxes.
2 Add Device Box – Allows user to define new relay boxes.
3 Delete Device Box – Allows you to delete any currently defined relay box.
4
Select - 2) Add Device Box then enter the address (0-15) of each relay box on the network.
The relay address entered in the Touch Pad must match one of the dip switch address set previously.
Section 6 - Programming Groups for EZ Pad Plus Touch Pads
Touch Pads are shipped without any predefined groups. If a user wants to operate items in a manner other than individually, you must define desired groups.
Group definitions are stored in each touch panel, so it will be necessary to define desired groups in every Touch Pad on network.
Groups can be different for each Touch Pad. Groups should only consist of items that can clearly be seen from the Touch Pad location.
1 Touch any key to start. At “Enter Password”, enter the Supervisor Password Code.
2 Press the Set Up key. This will show the options of: 1) Config System; 2) Config Group; 3) Config Device Box.
3 Select - 2) Config Group. This will show the options of:
1. Display Group – Shows already defined groups;
2. Add Group – Allows user to define new groups;
3. Delete Group – Allows you to delete any currently defined group.
4 Select - 2) Add Group.
5 Enter desired group number when prompted. Choose a group number that is not currently in use for that Touch Pad.
If a group number that is already in use is entered, a message indicating that group number is already registered will appear.
6 Select Device Type – Either UP
/
DOWN or AUX. A group can only contain one type of device.
7 When prompted enter device number to be included in group.
Enter first device number, then press enter; enter second device number then press enter, etc.
After all desired devices have been added to the group, press enter again to create group.
8 A group can consist of up to 8 devices (if 2 or more relay panels are in use), but can only include a maximum of two devices from each relay board.
(i.e. 1-4, 5-8, 11-14, etc)
Please Note: The system will not allow for the creation of a group that may overload a circuit. If an invalid group combination is entered, the error
message “Over PCB Limit (2 ea.) will appear. If this message is displayed, press the back key to start over on defining devices for this new group.
9 To edit or change a group it is necessary to delete that group number and redefine using above steps.
page 3 of 4
