Draper Foundation - Section 4 - Assembling Horizontal Rails

page 10 of 28
Foundation
™
for LED Panels
Section 4 - Assembling Horizontal Rails
The horizontal rails must be assembled prior being secured to the wall.
To assemble the Horizontal rails:
Align Outer Wall Brackets
within 24” (610mm) of the
end of horizontal rails
In some cases, not all provided
wall brackets will be used.
Align Outer Wall Brackets
within 24” (610mm) of the
end of horizontal rails
In some cases, not all provided
wall brackets will be used.
MAX. WALL BRACKET SPACING
32”
(813mm)
Slide Rail Section B
over Rail Splices
Slide Rail Section B
over slats in wall bracket
Slide Rail Splices
into slots in Section A
Tighten all rail splice screws
with 5mm hex wrench
2
1
3
10
9
8
7
6
5
4
3
2
1
8
7
6
5
4
3
2
1
4
3
2
1
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
12
11
5
4
3
2
1
WIDE
WIDE
WIDE
WIDE
WIDE
WIDE
SPLICE SPLICE
Horizontal Rails for Standard Array Sizes
Note: For Array sizes that require more than one Rail Splice (8 wide or more),
you MUST locate the wall mounting brackets on the center rail
section prior to securing splices.
