page 23 of 28

Foundation

™

for LED Panels

Section 13 - Installing Bottom Trim (must be done prior to LED Installation)

Section 13.1 - Installing BOTTOM Trim Sections

BOTTOM TRIM

Section 12.4 - Installing Bottom Trim brackets

SPLIT LOCK

WASHER -

SOCKET HEAD

SCREW

M4-0.7x10mm

BOTTOM VIEW

SOCKET HEAD

SCREW

M4-0.7x8mm
