Draper Foundation - Section 2 - Components

page 4 of 28
Foundation
™
for LED Panels
Section 2 - Components
SCREW
M8-1.25x10mm
Long Flanged
Button Head
Differential
Screw
3mm Hex Wrench
WALL
ADJUSTMENT
BRACKETS
VERTICAL
RAIL
COUPLER
7 High or More
VERTICAL
RAIL - TOP
7 High or More
VERTICAL
RAIL -
BOTTOM
7 High or More
WALL MOUNTING
BRACKET
M10 Spring-Loaded LED
Mounting Stud
LED Cabinet
(Not Included)
LED
Alignment
Tool
VERTICAL
RAIL
6 High or Less
HORIZONTAL RAILS
PLUM
ALIGNMENT
PIN
RAIL CONNECTOR
Top / Bottom Slot
RAIL CONNECTOR
Front Slot
PLUM
ALIGNMENT
PIN
RAIL CONNECTOR
Top / Bottom Slot
RAIL CONNECTOR
Front Slot
M10 Spring-Loaded LED
Mounting Stud
LED Cabinet
(Not Included)
Vertical Rail
Fasteners
SLIDE-IN NUT
M6-1.0
FLANGE HEAD SCREW
M6-1.0x12mm
