Draper Foundation - Page 5

page 5 of 28
Foundation
™
for LED Panels
Section 2 - Components
Component Part #
Standard Array Size
4 X 4 5 X 5 6 X 6 8 X 8 10 X 10 12 X 12
LED Panels By Others 16 25 36 64 100 144
WALL MOUNTING BRACKETS
C002.1603 10 12 14 27 33 39
WALL ADJUSTERS
Wall Adjuster Bracket C002.1604.02SA 10 12 14 27 33 39
Differential Socket Screw: M6 - 1x32.6mm
C020.725 10 12 14 27 33 39
HORIZONTAL RAILS
90" (2286mm) Horizontal Rail C285.062.001 0 2 2 0 6 8
93" (2362mm) Horizontal Rail C285.062.002 2 0 0 6 0 0
Horizontal Rail Section (length varies) C285.062 0 2 2 0 3 3
Length 0mm 688mm 1297mm 0mm 1453mm 388mm
HORIZONTAL RAIL CONNECTOR - Top/Bottom
Washer: .255"ID X .562"OD X .06" C013.012 10 28 30 75 81 111
Split Lock Washer: .25" ID X .365"OD X .063" C013.028 10 28 30 75 81 111
Screw: M6 - 1x10mm
C020.729 0 16 16 48 48 72
HORIZONTAL RAIL CONNECTOR - Front
Horizontal Rail Connector C162.032 0 6 6 18 18 27
Set Screw: M6 - 1x8mm
C020.728 0 8 8 24 24 33
VERTICAL RAIL FASTENERS
Slide-In Nut: M6 C018.165 10 12 14 27 33 39
Flanged Socket Head Screw: M6 - 1x9mm
C020.735 10 12 14 27 33 39
LED ALIGNMENT & ATTACHMENT TOOLS
M10 Spring Loaded LED Mounting Stud C021.041 64 100 144 256 400 576
LED Plum Alignment Pin C032.126 6 6 6 9 9 9
LED Alignment Tool
C202.039 2 2 2 2 2 2
VERTICAL RAILS
Vertical Rail Coupler C010.588 0 0 0 9 11 13
Flanged Button Head Screw: M8 - 1.25x10mm C020.727 0 0 0 36 44 52
Vertical Rail: 4 High Array / Lower for 8 High Array C056.070SA 5 0 0 9 0 0
Vertical Rail: 5 High Array / Lower for 10 High Array C056.071SA 0 6 0 0 11 0
Vertical Rail: 6 High Array / Lower for 12 High Array C056.072SA 0 0 7 0 0 13
Vertical Rail: Upper for 8 High Array C056.074SA 0 0 0 9 0 0
Vertical Rail: Upper for 10 High Array C056.075SA 0 0 0 0 11 0
Vertical Rail: Upper for 12 High Array C056.076SA 0 0 0 0 0 13
