Foundation
™
for LED Panels
Trim Component
Part #
Standard Array Size
4 X 4 5 X 5 6 X 6 8 X 8 10 X 10 12 X 12
TOP/SIDE TRIM BRACKETS
Top Trim Support Bracket
C002.1639.02SA 3 3 3 4 5 6
Trim Attachment Bracket (Top & Side) C002.1609SA 16 20 24 32 41 47
Screw: M4 - 0.7x10mm C020.621 32 40 48 64 82 94
Split Lock Washer: M4
C013.196 32 40 48 64 82 94
BOTTOM TRIM BRACKETS
Bottom Trim Attachment Bracket
C002.1638.02SA 5 6 7 9 11 13
Screw: M4 - 0.7x8mm Black Oxide
C020.739 4 4 4 6 8 8
TRIM SECTIONS
TRIM - TOP CENTER C287.147SA 0 0 0 1 2 0
TRIM - TOP CENTER C287.148SA 0 0 0 0 0 2
TRIM - TOP LEFT C287.149SA 1 1 0 0 0 0
TRIM - TOP LEFT C287.150SA 0 0 1 1 1 1
TRIM - TOP RIGHT C287.151SA 1 0 0 0 0 0
TRIM - TOP RIGHT
C287.152SA 0 1 1 1 1 1
TRIM - LT SIDE
C287.122SA 1 0 0 0 0 0
TRIM - LT SIDE C287.123SA 0 1 0 0 0 0
TRIM - LT SIDE C287.124SA 0 0 1 0 0 0
TRIM - LEFT SIDE BOTTOM C287.126SA 0 0 0 1 0 0
TRIM - LEFT SIDE BOTTOM C287.127SA 0 0 0 0 1 0
TRIM - LEFT SIDE BOTTOM C287.128SA 0 0 0 0 0 1
TRIM - LEFT SIDE TOP C287.130SA 0 0 0 1 0 0
TRIM - LEFT SIDE TOP C287.131SA 0 0 0 0 1 0
TRIM - LEFT SIDE TOP
C287.132SA 0 0 0 0 0 1
TRIM - RIGHT SIDE BOTTOM
C287.134SA 0 0 0 1 0 0
TRIM - RIGHT SIDE BOTTOM C287.135SA 0 0 0 0 1 0
TRIM - RIGHT SIDE BOTTOM C287.136SA 0 0 0 0 0 1
TRIM - RIGHT SIDE TOP C287.138SA 0 0 0 1 0 0
TRIM - RIGHT SIDE TOP C287.139SA 0 0 0 0 1 0
TRIM - RIGHT SIDE TOP C287.140SA 0 0 0 0 0 1
TRIM - RIGHT SIDE C287.144SA 1 0 0 0 0 0
TRIM - RIGHT SIDE C287.145SA 0 1 0 0 0 0
TRIM - RIGHT SIDE
C287.146SA 0 0 1 0 0 0
TRIM - BOTTOM CENTER
C287.113SA 0 0 0 1 2 0
TRIM - BOTTOM CENTER C287.114SA 0 0 0 0 0 2
TRIM - BOTTOM LEFT C287.115SA 1 0 0 0 0 0
TRIM - BOTTOM LEFT C287.116SA 0 1 1 1 1 1
TRIM - BOTTOM RIGHT C287.117SA 1 1 0 0 0 0
TRIM - BOTTOM RIGHT
C287.118SA 0 0 1 1 1 1
