HALF: Both VCOs are being sent to VCF2.
VCO1
VCA
VCF1
LP
HP
VCO2 VCF2
LP
HP
VCF ROUTE
LP: Stands for LOW PASS. Both lters are set to a Low Pass mode and in series.
VCA
VCF1
LP
HP
VCF2
LP
HP
VCA
VCF1
LP
HP
VCF2
LP
HP
VCA
VCF1
LP
HP
VCF2
LP
HP
VCA
VCF1
LP
HP
VCF2
LP
HP
BP: Stands for BAND PASS. The lters are in series, but VCF1 is on HP mode and VCF2 is on LP mode.
HP: Stands for HIGH PASS. The lters are in series and both are in High Pass mode.
PAR: Stands for PARALLEL. The lters are in Low Pass mode, but they are independant from each other.
x
x
x
x
x
x
x
x
7
