Parts List
5
FLEX 42x72 48x72 54x72 60x72 60x58 Shower and Tub Door manual Ver 1 Rev 4 072019
©2019 DreamLine. All Rights Reserved
This model is reversible for left or right-hand door installation. Determine the proper orientation
for the installation by considering access, shower head position and possible obstructions such
as a toilet or vanity. During the initial assembly, the entire frame can be flipped (upside down)
top to bottom for either left or right hand door installation.
1 Wall profile 2pcs
2 Panel Glass assembly
3 Wall anchor
4
5
6
Decorative cap and washer
7
Vinyl Seal with Flexible Fin 1pcs
8
Bottom Sweep Vinyl
1pc
13
Magnetic Strike Profile
14
Handle
1pc
15
1set
16
Top & Bottom pivot Rail
17
Door Glass
1pc
4pcs
ST4.2×10 Round head screw
8pcs
ST4.2×40 Truss head screw
10pcs
8pcs
10pcs
12
1pc
ST4.2×25 Round head screw
Top & Bottom pivot Hardware
2pcs
2pcs
Part#Part#
DESCRIPTION DESCRIPTION
QTY QTY
Right hand door installation
Left hand door installation
panel
panel
door
door
To Next Page
