Rotary Tool
Model number 800
Voltage rating 10.8 V
No load speed n
o
5,000-35,000/min
Collet Capacities 1/32”, 1/16”, 3/32”, 1/8”
Charger
Model number 856
Voltage rating 120 V 60 Hz
Amperage rating 375 mA
Charge time 3 Hr.
Page 7
Functional Description & Specifications
Disconnect battery pack from tool or place the switch in the locked or off position before
making any assembly, adjustments or changing accessories. Such preventive safety mea-
sures reduce the risk of starting the tool accidentally.
!
WARNING
Cordless Rotary Tool
COLLET
NUT
SWITCH
BATTERY
PACK
SHAFT LOCK
BUTTON
HANGER
CHARGER
COLLET
BATTERY
PACK
RELEASE
TAB
INDICATOR LIGHT
ALIGNMENT
ARROWS
