26
0BE=O $1>4B5< %? 0*has a
spring loaded sleeve and is used with sanding
bands.
1. Place EZ Drum™ mandrel into chuck as
deep as possible as possible as desscribed
on page 10.
%?D5 there is a blue spacer on the mandrel
that will bottom out on the EZ Change™
chuck, setting the mandrel to the correct
depth.
Always make sure the rotary
tool is “OFF” before changing
accessories. Incorrect seating of sanding band
on mandrel may lead to personal injury
orproperty damage.
+?<?141335CC?BI
2. As indicated, place two fingers underneath
the mandrel and pull firmly up. This will
place the EZ Drum™ in the "unlocked"
position (Fig. 1).
3. Keeping two fingers beneath the mandrel,
slide the sanding band down until the entire
blue mandrel is covered (Fig. 2).
4. To return to "locked" position, press firmly
down on the top of the mandrel (Fig. 3).
)5=?F9>7D85C1>49>721>4?>
D85=1>4B5<
1. Place two fingers underneath the mandrel
and pull firmly up. This will place the EZ
Drum™ in the "unlocked" position (Fig. 1).
2. Sanding band will now easily slide off
mandrel. (Do not squeeze sanding band
when removing from EZ Drum ™ mandrel.
This can lead to rubber band pulling off
mandrel and becoming inoperable (Fig. 3).
FIG. 1
FIG. 2
FIG. 3
!
WARNING
0BE=
™
&@5B1D9>7!>CDBE3D9?>C
