-7-
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
NOTE: For tool specifications refer to the nameplate on your tool.
FIG. 1
Model MM20 Multi-Max™ Oscillating Power Tool
VARIABLE SPEED
CONTROL DIAL
ON/OFF
SWITCH
POWER
CORD
VENTILATION
OPENINGS
ACCESSORY
CLAMPING
SCREW
ACCESSORY HOLDER
Model number MM20
No load speed n
0
10,000-21,000/min
Voltage rating 120 V 60 Hz
BLADE
WASHER
VENTILATION
OPENINGS
DM 2610015474 03-11:DM 2610015474 03-11.qxp 3/8/11 11:11 AM Page 7
