Functional Description and Specifications
D
isconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive
safety measures reduce the risk of starting the tool accidentally.
NOTE: For tool specifications refer to the nameplate on your tool.
FIG. 1
Model MM50 Multi-Max™ Oscillating Power Tool
Variable Speed
Control Dial
On/Off
Switch
Power
Cord
Ventilation
Openings
Accessory
Clamping
Flange
Model number MM50
No load speed n
0
10,000-21,000/min
Voltage rating 120 V 60 Hz
Ventilation
Openings
Clamping
Knob
Ventilation
Openings
Accessory
