Page 7For technical questions, please call 1-888-866-5797.Item 69487
SAFETYOPERATIONMAINTENANCE SETUP
2� Double insulated tools may be used in either of the
120 volt outlets shown in the preceding illustration�
(See Outlets for 2-Prong Plug.)
Extension Cords
1� Grounded tools require a three wire extension cord�
Double Insulated tools can use either
a two or three wire extension cord�
2� As the distance from the supply outlet increases,
you must use a heavier gauge extension cord�
Using extension cords with inadequately sized wire
causes a serious drop in voltage, resulting in loss of
power and possible tool damage� (See Table A.)
3� The smaller the gauge number of the wire, the
greater the capacity of the cord� For example,
a 14 gauge cord can carry a higher current
than a 16 gauge cord� (See Table A.)
4� When using more than one extension cord to make
up the total length, make sure each cord contains at
least the minimum wire size required� (See Table A.)
5� If you are using one extension cord for more
than one tool, add the nameplate amperes
and use the sum to determine the required
minimum cord size� (See Table A.)
6� If you are using an extension cord outdoors, make
sure it is marked with the suffix “W-A” (“W” in
Canada) to indicate it is acceptable for outdoor use�
7� Make sure the extension cord is properly wired
and in good electrical condition� Always replace
a damaged extension cord or have it repaired
by a qualified electrician before using it�
8� Protect the extension cords from sharp objects,
excessive heat, and damp or wet areas�
TABLE A: RECOMMENDED MINIMUM WIRE
GAUGE FOR EXTENSION CORDS* (120/240 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25´ 50´ 75´ 100´ 150´
0 – 2�0 18 18 18 18 16
2�1 – 3�4 18 18 18 16 14
3�5 – 5�0 18 18 16 14 12
5�1 – 7�0 18 16 14 12 12
7�1 – 12�0 18 14 12 10 -
12�1 – 16�0 14 12 10 - -
16�1 – 20�0 12 10 - - -
* Based on limiting the line voltage drop to five volts at
150% of the rated amperes.
Symbology
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc�
VAC
Volts Alternating Current
A
Amperes
n
0
xxxx/min�
No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury� Wear ANSI-approved
safety goggles with side shields�
Read the manual before
set-up and/or use�
WARNING marking
concerning Risk of Fire�
Do not cover ventilation ducts�
Keep flammable objects away�
WARNING marking concerning
Risk of Electric Shock�
Properly connect power cord
to appropriate outlet�
