Page 12 For technical questions, please call 1-800-444-3353. Item 69645
Specifications
Electrical Rating 120V~ / 60Hz / 4.3A
Motor No Load Speed 10,000 RPM
Max. Accessory Diameter 
Max. Accessory Thickness 1/4"
Arbor Hole Diameter 
Spindle Thread 
3146023
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical
outlet before assembling or making any adjustments to the tool.
Note: For additional information regarding the parts listed in the following pages,
refer to the Assembly Diagram near the end of this manual.
ASSEMBLY
Installing the Wheel Guard
TO PREVENT SERIOUS INJURY: Do not operate this tool without the Wheel Guard properly installed.
1. 
2. 

3. 
shield you during the planned work.
4. 
5. 
Adjust if necessary before proceeding.
Installing the Auxiliary Handle
TO PREVENT SERIOUS INJURY:
Do not operate this tool with one hand only or without the Auxiliary Handle properly installed.
1. The Auxiliary Handle may be installed
in one of three positions, on either side

2. Screw the threaded end of the
Auxiliary Handle into the selected position.
Tighten securely before beginning work.
