SKU 95578 For technical questions, please call 1-800-444-3353. Page 18
Part Description
1 Outer Flange Nut
3 Inner Flange
4N Wheel Guard
5N Wheel Guard Bolt
6N Wheel Guard Square Nut
7N Spindle
8N Woodruff Key
9N Screw
10N Spring Washer
12N Gearbox Bottom Cover
13 Bearing 60201
14 Locking Ring
15 Ring Gear
16 Locking Ring
17 Bearing
18N Side Handle
19N Screw
20N Keeper
21N Lock Spring
22N Spindle Lock Button
23N Gear Housing
24 Pinion Gear
25 Bearing 6018
26 Gearbox Back Cover
27N Self Tapping Screw
Part Description
28N Screw
29N Woodruff Key
30N Armature
31 Bearing 6018
32 Bearing Cover
33N Bolt
34N Stator
35N Sliding Spring
36N Wind Shield Ring
37N On/Off Switch
38N Power Switch
39N Lock Spring
40N Motor Housing
41N Carbon Brush Holder
42N Brush
43N Sliding Spring
44N Switch
45N End Cap Housing
46N Screw
47 Sheath (#115A)
48N Power Cord Bracket
49N Self Tapping Screw
50 Power Cord/Plug
51 Wrench
