Drive F22 - Introduction to the F-22 Rollator; F-22 Rollator Inclusions; Operating the F-22 Rollator; Unfolding the Rollator

The Walking aid is suitable for a single user with limited mobility. The F-22 Rollator is
ideal for indoor and outdoor use.
1. Bag
2. Back Rest
3. Operating Instructions
introduction
7. Seat
8. Bag
9. Front wheel
10. Brake adjust screw
11. Rear wheel
12. Safety bow
F-22 Rollator includes:
unfolding the F-22 Rollator
Position the F-22 Rollator
on its wheels. Open the
red safety bow and lift up
(figure 1). Press both pipes
from the seat downwards
until they interlock (figure
2).
height adjustment
Press the red release buttons for handgrips below,
as shown in figure 3, and pull the handgrip upwards
at the same time. As the handle moves, release the
button. This automatically locks in the next possible
height. Repeat this process until the desired height
is reached.
1
2
3
