adjustment of brakes
To adjust the braking
strength, adjust the
brake by pressing
the screw housing
downwards (figure 8)
and then turn left or
right (figure 9).
sitting
Position the F-22 Rollator on an even and solid
surface. Lock the brakes (parking position). The F-22
Rollator must stand and must not slip. Sit straight up
and do not lean backwards. (See figure 10).
DO NOT MOVE ROLLATOR WHILE SEATED.
folding / transport / storage
To fold, pull seat
upwards by the handle
on the seat plate as
shown in figure 11. The
F-22 Rollator can now
be folded complete and
secured by using the red
safety clasp as shown in
figures 12 and 13.
8 9
10
11 12
13
