DRIVE COMPRESSOR/NEBULIZER MODEL MQ5800, MQ5900, MQ5900P
.............................................................................................................................
16
Guidance and manufacturer’s declaration - electromagnetic Immunity
The Device is intended for use in the electromagnetic environment specied below. The customer or the user of
the Device should assure that it is used in such an environment
Immunity Test IEC 60601
Test level
Compliance level Electromagnetic environment - gui-
dance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
Floors should be wood, concrete or
ceramic tile. If oors are covered with
synthetic material, the relative humidity
should be at least 30 %
Electrical fast tran-
sient/burst
IEC 61000-4-4
Power supply lines:
±2 kV
input/output lines:
±1 kV
Power supply lines:
±2 kV
Mains power quality should be that of a
typical commercial or hospital environ-
ment.
Surge
IEC 61000-4-5
line(s) to line(s):
±1 kV.
line(s) to earth:
±2 kV.
100 kHz repetition
frequency
line(s) to line(s): ±1 kV.
100 kHz repetition
frequency
Mains power quality should be that of a
typical commercial or hospital environ-
ment.
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines
IEC 61000-4-11
5% UT
(>95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT)
for 5 cycle
70% UT
(30% dip in UT)
for 25 cycle
<5% UT
(>95% dip in UT)
for 5s
5% UT
(>95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT)
for 5 cycle
70% UT
(30% dip in UT)
for 25 cycle
<5% UT
(>95% dip in UT)
for 5s
Mains power quality should be that of a
typical commercial or hospital environ-
ment.
Power frequency
(50/60Hz)
magnetic eld
IEC 61000-4-8
30 A/m
50Hz/60Hz
30 A/m
50Hz/60Hz
Power frequency magnetic elds should
be at levels characteristic of a typical loca-
tion in a typical commercial or hospital
environment.
NOTE UT is the a.c. mains voltage prior to application of the test level.
