Drive PHOENIX HD 3 - Page 13

13
4. OPERATION
Fig 4.1 Fig 4.2
✮ Warning
Never operate the freewheel lever while seated on the scooter or on an incline!
OPERATION OF THE FREEWHEEL LEVER
‧ Always pull UP FIRMLY for freewheel mode
‧ Always push DOWN FIRMLY for drive mode
Tiller Adjustment
The tiller can be adjusted in to many different positions to suit each driver.
1. Loosen the knob to adjust the tiller to positions you want. (Fig. 4.3)
2. Once decide the position, tighten the knob to secure the tiller.( Fig.4.4)
Fig. 4.3 Fig. 4.4
✮ Warning
♦ Please hold the tiller before loosening the tiller adjustment knob.
♦ Before lifting or driving the scooter make certain the tiller adjustment knob is fully
tightened.
♦ Never attempt to adjust the tiller while the scooter is motion.
Adjustment
knob
Lever
Lever
