adjustment of brakes
To adjust the braking
strength, adjust the
brake by pressing
the screw housing
downwards (figure 8)
and then turn left or
right (figure 9).
sitting
Position the Nitro Rollator on an even and solid
surface. Lock the brakes (parking position). The Nitro
Rollator must stand and must not slip. Sit straight up
and do not lean backwards. (See figure 10).
DO NOT MOVE ROLLATOR WHILE SEATED.
folding / transport / storage
To fold, pull seat upwards
by the handle on the seat
place as showing in figure
11. The Nitro Rollator can
now be folded completely
and secured by pushing the
hand grips together until
an audible ‘click’ is heard.
This is when the underseat
locking mechanism is
engaged (figures 12 & 13).
8 9
10
11 12
13
