Drive Sunfire Plus EC - Armrest Height, Headrest, and Seat Removal

14
5 . O P E R AT I O N
▇ To adjust the armrests height
◆ Press the button.
◆ Move the armrest to the required position.
▇ To adjust the headrest
◆ To raise headrest , lift it to the desired position.
◆ To lower headrest, push release tab towards the inside of the wheelchair and lower the
headrest to the desired position.
▇ To remove the seat
1. Turn the power OFF.
2. Make sure the Sunfire Plus EC is not in freewheel mode.
3. Push the seat rotate lever while pulling up on the seat to remove.
Knob
Adjust The Headrest
