Blackcomb Installation and Operation Manual
53
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your stove, please provide the model number and the serial number. We reserve
the right to change parts due to technology upgrade or availability. Contact an authorized
dealer to obtain any of these parts. Never use substitute materials. Use of non-approved
parts can result in poor performance and safety hazards.
# Item Description QtY
1 AC07867 1/2 " CHROME PLATED COIL HANDLE 1
2 SE24085 DOOR FRAME WITH HANDLE AND GASKET WITHOUT GLASS 1
3 AC06200 BLACK GASKET AND SILICONE KIT 1/4'' X 1/2'' X11' 1
4 AC09165 HANDLE AND LATCH KIT 1
5 AC09185 DOOR LATCH KIT 1
6 30055 HINGE PIN RETAINING RING 5/16" ID X 0.512" OD 2
7 30170 HINGE PIN 5/16" DIA X 1 1/2" LONG 2
8 30101 SPRING TENSION PIN 5/32" DIA X 1 1/2" LONG 1
9 SE08537-10
ARCHED REPLACEMENT GLASS WITH GASKET 7 7/8" X 16 3/4" X 8
25/32"
1
10 AC06400 BLACK SELF-ADHESIVE GLASS GASKET KIT (6') 1
11 PL08537-05 BOTTOM GLASS RETAINER 1
12 PL08537-04 TOP GLASS RETAINER 1
13 30124 SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC 8
14 30060
THREAD-CUTTING SCREW 1/4-20 x 1/2" F HEX STEEL SLOT WASHER
C102 ZINC
10
15 PL53791 ASH LIP 1
16 PL53804 ASH LIP SUPPORT 1
17 PL65572 AIR CONTROL ROD GUIDE 1
18 SE65561 AIR CONTROL ROD ASSEMBLY 1
19 AC07863 1/4 " CHROME PLATED LONG COIL HANDLE 1
20 30131 BLACK METAL SCREW #10 X 1/2" TYPE "A" PAN QUADREX 12
21 PL53803 REAR PLATE OF PEDESTAL 1
22 30418 FINISHING PLUG 3/8" 2
23 99999 BUILD TO ORDER 1
24 PL53797 AIR CONTROL COVER 1
25 SE53931 ASH DRAWER 1
26 30206 ZINC WASHER ID=5/16" x OD=3/4" 1
27 SE53529 AIR CONTROL DAMPER WITH HARDWARE 1
28 30187 ZINC WASHER ID 17/64" x OD 1/2" 1
29 30064 3/16" X 1" CLEVIS PIN 1
30 30059 5/32" ID PUSHNUT 2
31 AC01336 PEDESTAL WOOD STOVE FRESH AIR ADAPTER KIT 1
32 PL53795 DECORATIVE PANEL 2
33 99999 BUILD TO ORDER 1
34 PL06748-01 LEFT HAND SIDE BLOWER SUPPORT 1
