FLOOR PROTECTOR
If the stove is to be installed on top of a combustible floor, it must be guarded by a non
combustible material as shown on figure 2 (see the dotted line area).
FLOOR PROTECTOR*
CANADA USA
G
8’’ (205 mm) – Note 1 N/A (Canada only)
H
8’’ (205 mm) N/A (Canada only)
I
18’’ (460 mm)
From door opening
16’’ (410 mm)
From door opening
J
N/A (USA only) 8’’ (205 mm)
M
8’’ (205 mm) N/A (Canada only)
N
N/A (USA only) Note 2
*Steel with a minimum thickness of 0.015’’ (0.38 mm) or ceramic tiles sealed together
with grout. No protection is required if the unit is installed on a non-combustible floor
(ex: concrete).
Note 1: The floor protection at the back of the stove is limited to the stove’s required
clearance if such clearance is smaller than 8 inches (205 mm).
Note 2: Only required under the horizontal section of the connector. Must exceed each
side of the connector by at least 2 inches (51 mm).
