Drolet HT-3000 - Dimensions

Page 10
Installation and Operation Manual - HT-3000
ENGLISH
2.3 Dimensions
14 1/8"
357mm
28 1/8"
714mm

6"
153mm
9"
230mm
25 3/4"
653mm
18 3/8"
467mm
12 1/8"
308mm
Figure 1: Top view Figure 2: Front view
25"
636mm
31 1/4"
794mm
36 3/8"
925mm
24 3/16"
615mm
35 1/8"
894mm
20 1/8"
510mm
12 7/8"
326mm
5/16"
8mm
3/16"
5mm
Figure 3: Side view Figure 4: Combustion chamber - side view
22 7/8"
581mm
19"
483mm
10 5/8"
269mm
Figure 5: Combustion chamber - front view Figure 6: Door opening
