Page 50
Installation and Operation Manual - HT-3000
ENGLISH
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for your unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrades or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 AC01281 RIGID FIRE SCREEN 1
2 30569 ROUND WOODEN HANDLE BLACK 2
3 SE24325 DROLET DOOR ASSEMBLY 3.5 SERIES 1
4 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 1
5 AC07867 1/2" CHROME PLATED COIL HANDLE 1
6 SE70697 REPLACEMENT HANDLE WITH LATCH KIT 1
7 AC09185 DOOR LATCH KIT 1
8 30101 SPRING TENSION PIN 5/32"Ø X 1 1/2"L 1
9 SE70903 DROLET GLASS DOOR 3.5 SERIES 1
10 AC06400 3/4" (FLAT) X 6' BLACK SELF-ADHESIVE GLASS GASKET 1
11 PL70833 LEFT GLASS FRAME 1
12 PL70832 RIGHT GLASS FRAME 1
13 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
14 30154 BLACK SCREW #10 X 5/8" QUADREX #2 TYPE A 2
15 PL70774 AIR CONTROL COVER 1
16 30507 BLACK TORX SCREW WITH FLAT HEAD TYPE F 1/4-20 X 3/4" 4
17 PL70849 ASHTRAY DECORATIVE MOULDING 1
18 PL70836 ASH SHELF 1
19 30187 STAINLESS WASHER ID 17/64" X OD 1/2" 1
20 SE70904 AIR DAMPER ASSEMBLY 1
21 30206 ZINC WASHER 5/16"ID X 3/4"OD 1
22 30506 SCREW PAN TORX TYPE F 1/4-20 X 1" BLACK 3
23 30429 3/8'' NICKEL COIL HANDLE 1
24 PL70846 RIGHT SIDE DECORATIVE PANEL 1
25 PL70847 LEFT SIDE DECORATIVE PANEL 1
26 PL70851 DECORATIVE GRILL 1
27 30138 METAL SCREW #6 3/8'' QUADREX ''A'' TYPE BLACK 1
28 29010 4 1/2" X 9" X 1 1/4" REFRACTORY BRICK 17
29 29015 4'' X 9'' X 1 1/4'' REFRACTORY BRICK 4
30 PL36056 2" X 9" 1 1/4" REFRACTORY BRICK 8
31 PL36760 3 1/4" X 4 1/2" X 1 1/4" REFRACTORY BRICK 1
32 PL70864 SECONDARY AIR TUBE 4
33 21585 VERMICULITE BAFFLE 1
34 AC02055 QUICK CONNECT THERMODISC KIT 1
35 44028 CERAMIC THERMODISC F110-20F 1
36 PL05530-02 THERMODISC BOX (COVER) 1
37 60013 POWER CORD 96" X 18-3 type SJT (50 pcs per carton) 1
