Drolet UL 1482 - Technical Specifications

3
TECHNICAL SPECIFICATIONS
Recommended Surface:
850 to 1850 sq. ft.
(79 to 172 m
2
)
Maximum heat output (EPA test fuel) :
Maximum heat output (seasoned cordwood):
13,19kW (45,000 BTU)
16.41 kW (56,000 BTU)
Maximum efficiency (default EPA efficiency) :
63%
Average emissions (EPA):
6.4 g/hr.
Paint finish :
Metallic black
Flue outlet (spigot) diameter :
6” (152 mm)
Maximum Log Length :
19’’ (483 mm)
Overall dimensions (W x D x H):
25 ¼’’ x 26’’ x 30 ½’’
(642 mm x 661 mm x 775 mm)
Firebox dimensions (W x D):
Firebox volume:
21’’ x 16 ½’’
(532 mm x 420 mm)
2.22 cubic feet
(0,062 m
3
)
Door opening (W x H) :
17 ½’’ x 9’’
445 mm x 229 mm
Weight:
374 lbs (171 kg)
OPTIONS PART NUMBER
Blower kit AC03095
