Dromone Multi– Lock Quick Coupler
QMS 22 Dromone Multi– Lock Quick Coupler Author:EOD
REV: D - JAN2012 15 Approved:MS
Maintenance Schedule
The table below is to be used as a guideline in the maintenance program of the
coupler. The maintenance log should be update and signed off at the recommended
hourly interval. If parts are damaged or worn outside of the schedule below these
Description Hourly Interval
1000 2000 3000 4000 5000 6000
Latching Hook Assy (Ref 1)
INSPECT INSPECT INSPECT INSPECT INSPECT REPLACE
Signed
Date
Bucket Pins (Ref 4 and 5)
INSPECT INSPECT INSPECT REPLACE INSPECT INSPECT
Signed
Date
Hydraulic Cylinder ~Lg (Ref 12)
INSPECT INSPECT INSPECT INSPECT INSPECT INSPECT
Signed
Date
Hydraulic Cylinder ~S (Ref 11)
INSPECT INSPECT INSPECT INSPECT INSPECT INSPECT
Signed
Date
Front lock (Ref 7)
INSPECT INSPECT INSPECT INSPECT INSPECT INSPECT
Signed
Date
Cylinder Pin (Ref 6)
INSPECT INSPECT INSPECT INSPECT REPLACE INSPECT
Signed
Date
Hook Assy Pin (Ref 3)
INSPECT INSPECT INSPECT INSPECT REPLACE INSPECT
Signed
Date
Cylinder & Hook Pin (Ref 2)
INSPECT INSPECT INSPECT INSPECT INSPECT INSPECT
Signed
Date
Rear lock (Ref 10)
INSPECT INSPECT INSPECT INSPECT INSPECT INSPECT
Signed
Date
Check Valves (Ref 16)
INSPECT INSPECT INSPECT REPLACE INSPECT INSPECT
Signed
Date
Seal Kits (Ref 15)
INSPECT INSPECT INSPECT REPLACE INSPECT INSPECT
Signed
Date
Push Bar (Ref 8)
INSPECT INSPECT INSPECT INSPECT REPLACE INSPECT
Signed
Date
Front lock pin kit (Ref 9)
INSPECT INSPECT INSPECT INSPECT REPLACE INSPECT
Signed
Date
