94
Safety
05
IUF: seat suitable for installing an Isofix
Universal seat, "Forward facing", secured
using the upper strap.
IL : seat suitable for installing an Isofix Semi-
Universal seat which can be:
– "rearward facing" fitted with an upper
strap or a support leg.
– "forward facing" fitted with a support leg.
– a carrycot fitted with an upper strap or a
support leg.
X : seat not suitable for installing an ISOFIX seat
or carrycot of the weight group indicated.
For information on securing the upper strap using
the ISOFIX mountings, refer to the corresponding
section.
(a) Refer to the current legislation in your
country before installing a child at this seat
position.
(b) Tilt the seat backrest to 45°, then install the
child seat.
Straighten the backrest until it is in contact
with the child seat's backrest.
i-Size child seats
i-Size child seats have two latches that are anchored to the two rings A.
These i-Size child seats also have:
– either an upper strap that is attached to ring B.
– or a support leg that rests on the vehicle floor, compatible with the approved i-Size seat position.
Their role is to prevent the child seat from tipping forward in the event of a collision.
For more information on the ISOFIX mountings, refer to the corresponding section.
In accordance with European regulations, this table indicates the options for installing i-Size child seats on seats in the vehicle fitted with ISOFIX mountings
approved for i-Size.
Seat Front passenger airbag i-Size restraint system
Row 1 (a) Manually-adjustable passenger seat (b) Deactivated "OFF" i-U
Activated "ON" i-UF
Electrically-adjustable passenger seat Deactivated "OFF" Not i-Size
Activated "ON" Not i-Size
Row 2 Rear outer seats i-U
Rear central seat Not i-Size
