/ (Figura F)
/ (Figura H)
/ (Figura G)
/ (Figura I) / (Figura J)
5.
6.
Driver’s side speaker removal / Extracción del altavoz del lado del conductor
7.
8.
(Figure I)
(Figure F)
(Figure G)
(Figure H)
(Figure J)
6
Remove (8) Phillips screws securing the instrument panel on
the left side, and airbag panel on the right side. (Figure F, G)
Unclip the steering column shroud then set aside. (Figure H)
Open the driver’s door, then unclip and remove the
panel on the side of the dash. Remove (5) Phillips
screws exposed. (Figure I)
Abra la puerta del conductor, luego desenganche y
retire el panel en el costado del tablero. Retire (5)
tornillos Phillips expuestos. (Figure I)
Remove (5) Phillips screws securing the speaker
panel, then unclip and remove. (Figure J)
Quite los (5) tornillos Phillips que sujetan el panel
del altavoz, luego desenganche y retire. (Figure J)
Suelte la cubierta de la columna de dirección y déjela a un
lado. (Figura H)
Quite los (8) tornillos Phillips que sujetan el panel de instru-
mentos en el lado izquierdo y el panel de la bolsa de aire en el
lado derecho. (Figura F, G)
