DSC PC1575 Program Sheet
[06] PGM Output Programming (PGM 1 and 2)
Default
19 I _ _I _ _I PGM 1
10 I _ _I _ _I PGM 2
Programmable Output Options
01 Ground Start Pulse 12 Police Code Follower
02 User Output with Any Code 13 20 Minute Latched Alarm
[*] [7] [1] + Access Code 14 Line Seizure
03 Sensor Reset [*] [7] [2] 15 Ready to Arm Status
04 Courtesy Pulse 16 Links Support (PGM 1 only)
05 Keypad Buzzer Follow Mode 17 Downlook Support
06 System Armed Status 25 2-Wire Smoke (PGM 2 only)**
07 Strobe Output 26 Momentary Keyswitch Arm (PGM2)
08 Fail to Communicate (TLM Output) 27 Maintained Keyswitch Arm (PGM2)
09 Entry Delay Follower 28 Silent 24 Hour (PGM2)
10 Exit Delay Follower 29 Audible 24 Hour (PGM2)
11 TLM and Alarm 30 Forced Answer (PGM2)
**For 2-Wire Smoke Support Jumper CON1 on board must be removed
[07] Keypad Lockout Options
Default
00 I _ _
I _ _I Number of Invalid Codes Before Lockout (001-255 codes)
00 I _ _
I _ _I Lockout Duration (001-255 minutes)
[08] First System Option Code (Toggle Options ON/OFF, Press # to Exit)
Default Option ON OFF
OFF I _ _
I 1 Normally Closed Loops End-of-Line Resistors
OFF I _ON _
I 2 Double End-of-Line Resistors Single End-of-Line Resistors
ON I _ON _
I 3 Fire Key Enabled Disabled
OFF I _ON _
I 4 Police Key Audible Silent
ON I _ON _
I 5 TLM Enabled Disabled
OFF I _ON _
I 6 TLM Audible when Armed TLM Trouble Only
[09] Second System Option Code (Toggle Options ON/OFF, Press # to Exit)
Default Option ON OFF
OFF I OFF_
I 1 Master Code Not Changable Master Code Changable
OFF I OFF_
I 2 Code Required to Bypass No Code Required
OFF I _ON _
I 3 6th Code is Duress Code 6th Code is Normal Code
OFF I OFF_
I 4 Quick Exit Enabled Quick Exit Disabled
OFF I OFF_
I 5 Bypass Status Displayed w/Armed Bypass Not Displayed w/Armed
ON I _ON _
I 6 AC Trouble Displayed AC Trouble Not Displayed
[10] Third System Option Code (Toggle Options ON/OFF, Press # to Exit)
Default Option ON OFF
OFF I OFF_
I 1 Arm/Disarm Bell Squawk Enabled Disabled
OFF I OFF_
I 2 Bell Squawk During Auto Arm Disabled
OFF I OFF_
I 3 Bell Squawk On Exit Delay Disabled
OFF I OFF_
I 4 Bell Squawk On Entry Delay Disabled
ON I _ON _
I 5 Audible Exit With Urgency Silent Exit Delay
ON I _ON _
I 6 Quick Arm Enabled Quick Arm Disabled
[11] Fourth System Option Code (Toggle Options ON/OFF, Press # to Exit)
Default Option ON OFF
OFF I OFF_
I 1 For Future Use
ON I _ON _
I 2 Event Buffer Follow Swinger Event Buffer always ON
ON I _ON _
I 3 Trouble Light Flashes if AC Fails Light does not Flash
OFF I OFF_
I 4 Exit Delay Termination Enabled Disabled
OFF I OFF_
I 5 Keypad Blanking Enabled Disabled
OFF I OFF_
I 6 Keypad Tampers Enabled Disabled
Zone Attributes (Normally leave alone)
ON Audible Steady Chime Force Bypass Downlook
OFF Silent Pulsed No No No No
[21] Zone 1
I _ _I I _ _I I _ _I I _ _I I _ _I I _ _I
[22] Zone 2 I _ _I I _ _I I _ _I I _ _I I _ _I I _ _I
[23] Zone 3 I _ _I I _ _I I _ _I I _ _I I _ _I I _ _I
[24] Zone 4 I _ _I I _ _I I _ _I I _ _I I _ _I I _ _I
[25] Zone 5 I _ _I I _ _I I _ _I I _ _I I _ _I I _ _I
[26] Zone 6 I _ _I I _ _I I _ _I I _ _I I _ _I I _ _I
Created by Mark Leuck 02/02/2002 Monitronics International, Inc.
