play/stop; when setting the address, this
button is used to exit the setting status.
 “F1” Button: When adjusting the volume,
this button is used to switch over among
three sound sources including auxiliary
input, microphone input, and MP3.
 “Set” Button: This is the local setting
button. Long press this button to enter the
IP address checking status; press again to
enter the IP setting status.
 “VOL-” Button: In the mode of playing,
this button is used to decrease the volume;
in the mode of checking IP, this button is
used to switch over the parameters
selected for checking; in the mode of IP
setting, this button is used to add or
subtract the parameter.
4 Infrared remote control receiving window
5 Digital display screen
 The digital display screen is used to
display the local working condition and
network information status and to display
the time.
6 Signal indicator lamp
 Net Service: Network indicator lamp. If the
machine is connected successfully to the
host with the network, this indicator lamp
is on.
 Timing: Timing-point indicator lamp. This
power amplifier may execute the off-host
timing point edited on the host. When this
terminal is able to execute the timing point
off the host, this indicator lamp is on.
 Signal: Power amplifier output level
indicator lamp. In case of the signal output
from this power amplifier, this indicator
lamp is on; when the volume of the power
amplifier increases gradually, this indicator
lamp is lightened gradually; when the
volume decreases gradually, this indicator
lamp is darkened gradually.
 CILP: Voltage limiting function indicator
lamp; if the voltage limiting function
indicator lamp is on, it indicates the
excessively large output signal, and the
voltage limiting circuit is activated.
 PROT: Power amplifier indicator lamp. In
case of the protection against the faults
such as over-current, overheat, short circuit
of the power circuit, this indicator lamp is
on.
Remark: No indication function is
opened on the CLIP indicator lamp and
PROT indicator lamp in MAG6806.
7 Cabinet fixing screw hole for installation of
machine
